ARES ST

Expert Sports
Perimeter Solution

> Applications

Stadiums for various sports events.

> FEATURES

Front and rear access available for module, fast installation and disassembly..

  • Module applies hard connection, less failure-rate, enabling time-saving maintenance.
  • Rubber mask and soft cushion design, protecting from collision injury during intense competition.
  • 160° viewing angle, improving shooting effect of side camera, maximizing advertising revenue.
  • High refresh rate, stable image without switching flicker in live broadcast.
  • Fully waterproof design, high protection rating, fan-less and super silent design.

> TECHNICAL PARAMETER

Model No. ARES LT 10 ARES LT 12.5
Pixel Pitch(mm) 10mm 12.5mm
LED SMD SMD
Brightness(cd/m2 ≥6000 ≥6000
Refresh Rate(Hz) ≥3840 ≥3840
Power Consumption(Max/Ave) (W/m2) 700/280 700/280
Scan #### ####
Module Resolution(px) 50×10 40×8
Module Size(mm) 500×100 500×100
Panel Resolution(px) 100×(60,70,80,90,100,110,120) 80×(48,56,64,72,80,88,96)
Panel Display Size(mm) 1000×(600,700,800,900,1000) 1000×(600,700,800,900,1000)
Panel Size(mm) 1000×(655,755,855,955,1055)×120 1000×(655,755,855,955,1055)×120
Weight(kg/m2) 35 35
IP Rating(Front/Rear) IP40/IP40 IP40/IP40
Gray Scale(Bit) 19 19
Maintenance Front/Rear Front/Rear
Operating Temperature/Humidity(℃/RH) -20~50/10~90% -20~50/10~90%
